Rubber lined double flange joint Rubber expansion joint dual-ball flexible rubber jointsingle ball flexible rubber joint flexible rubber reducer joint

Rubber joints are mainly made of elastic rubber and absorb pipes and lines through efficient expansion and deformation, producing dimension change compensation and shock absorption elements. The product can reduce vibration and noise, and can compensate for thermal expansion and cold contraction caused by temperature change, and is widely used in various pipeline systems. We have a professional and experienced service team, and our cooperation will take your career to a higher level.

Category：

Pipe Fitting

E-mail:

sales@successmach.com

Inquiry

Recommend

Description

Dimensinons

DN	PN	L	PCD	n-d	Axial Displacement		Lateral Displacement	Angular Deflection
DN	PN	L	PCD	n-d	Elongation	Compression	Lateral Displacement	Angular Deflection
50	10	105	125	4-19	7	10	10	15
65	1.0	115	145	4-19	7	13	11	15
80	1.0	135	160	8-19	8	15	12	15
100	1.0	150	180	8-19	10	19	13	15
125	1.0	165	210	8-19	12	19	13	15
150	1.0	180	240	8-23	12	20	14	15
200	1.0	210	295	8-23	16	25	22	15
250	1.0	230	350	12-23	16	25	22	15
300	1.0	245	400	12-23	16	25	22	15
350	1.0	255	460	16-23	16	25	22	15
400	1.0	255	515	16-28	16	25	22	15
450	1.0	255	565	20-28	16	25	22	15
500	1.0	255	620	20-28	16	25	22	15
600	1.0	260	725	20-31	16	25	22	15
700	1.0	260	840	24-31	16	25	22	15
800	1.0	260	950	24-34	16	25	22	15
900	1.0	260	1050	28-34	16	25	22	15
1000	1.0	260	1160	28-37	18	26	24	15
1200	1.0	260	1380	32-41	18	26	24	15
1400	1.0	260	1590	36-44	20	28	26	15
1600	1.0	350	1820	40-50	25	28	30	10
1800	1.0	400	2020	48-50	25	30	30	10
2000	1.0	450	2230	48-50	25	30	30	10
2200	1.0	500	2440	52-56	25	35	30	10
2400	1.0	500	2650	56-56	25	35	30	10
2600	1.0	500	2850	50-56	25	35	30	10
2800	1.0	500	3070	64-56	25	35	30	10
3000	1.0	500	3290	68-62	25	35	30	10
