Foot Valve Bottom Valve H42X Flanged bottom valve

This is a valve that is installed at the bottom of the inlet pipe of the pump to prevent the water in the pipe from flowing back to the pump to reverse or damage when the pump stops working . The bottom valve is simply in structure, mainly composed of valve body, valve cover, valve disc, spring and so on. Working principle: When the pump is working, the water flow through the valve body, the valve disc is lifted under the action of water pressure, so that the water flow through; When the pump stops working, the valve disc automatically closes under the action of the spring, preventing water from flowing into the flow。 We have a professional and experienced service team, and our cooperation will take your career to a higher level.

Category：

Foot Valve

E-mail:

sales@successmach.com

Inquiry

Recommend

Description

The foot valve is a one-way valve installed at the foot of the pump suction line to prevent backflow of fluid when the pump stops running. Foot valves play an important role in fluid transfer systems in many industrial and civilian fields, ensuring the normal operation of the pump and the stability of the system.

1. Structure

Foot valve usually consists of valve body, valve flap, valve stem, spring and other components. Valve body is the main part of the valve, usually cast or forged, with internal flow path and valve seat. Valve flap is the key component to control the flow of fluid, generally circular or conical, connected to the spring through the valve stem. The role of the spring is to provide a certain amount of preload when the valve flap is closed, to ensure that the valve flap can closely fit the valve seat to prevent backflow.

2、Working Principle

When the pump starts, the liquid enters the foot valve from the suction pipe, overcomes the resistance of the spring under the action of liquid pressure, pushes the valve flap open, and the liquid enters the pump body through the foot valve smoothly. When the pump stops running, the pressure of liquid backflow acts on the valve flap to close the valve flap, thus preventing the liquid from flowing

3. Fields of application

a. Water supply and drainage systems

In the water supply and drainage system, the foot valve is used to prevent water from flowing backward when the pump stops running and to ensure the normal operation of the system.

b. Chemical industry

In chemical production, the transport of various liquid media often needs to use the foot valve to control the flow of fluid and prevent backflow.

c. Oil industry

Foot valves play an important role in the suction pipe of oil pumps during oil extraction, transmission and processing.

d. Electricity industry

Foot valves are also used in cooling systems, circulating water systems, etc. in power plants.
